Compiling Scheme to WebAssembly

Highlights

The most interesting aspect of this project was working with WASM GC to represent Scheme objects. As long as we properly box/wrap all values in refs, the underlying WASM execution environment will take care of the memory management.

For Bob, here's how some key Scheme objects are represented:

;; PAIR holds the car and cdr of a cons cell.
(type $PAIR (struct (field (mut (ref null eq))) (field (mut (ref null eq)))))

;; BOOL represents a Scheme boolean. zero -> false, nonzero -> true.
(type $BOOL (struct (field i32)))

;; SYMBOL represents a Scheme symbol. It holds an offset in linear memory
;; and the length of the symbol name.
(type $SYMBOL (struct (field i32) (field i32)))

$PAIR is of particular interest, as it may contain arbitrary objects in its fields; (ref null eq) means "a nullable reference to something that has identity". ref.test can be used to check - for a given reference - the run-time type of the value it refers to.

You may wonder - what about numeric values? Here WASM has a trick - the i31 type can be used to represent a reference to an integer, but without actually boxing it (one bit is used to distinguish such an object from a real reference). So we don't need a separate type to hold references to numbers.

Also, the $SYMBOL type looks unusual - how is it represented with two numbers? The key to the mystery is that WASM has no built-in support for strings; they should be implemented manually using offsets to linear memory. The Bob WASM compiler emits the string values of all symbols encountered into linear memory, keeping track of the offset and length of each one; these are the two numbers placed in $SYMBOL. This also allows to fairly easily implement the string interning feature of Scheme; multiple instances of the same symbol will only be allocated once.

Consider this trivial Scheme snippet:

(write '(10 20 foo bar))

The compiler emits the symbols "foo" and "bar" into linear memory as follows [3]:

(data (i32.const 2048) "foo")
(data (i32.const 2051) "bar")

And looking for one of these addresses in the rest of the emitted code, we'll find:

(struct.new $SYMBOL (i32.const 2051) (i32.const 3))

As part of the code for constructing the constant cons list representing the argument to write; address 2051 and length 3: this is the symbol bar.

Speaking of write, implementing this builtin was quite interesting. For compatibility with the other Bob implementations in my repository, write needs to be able to print recursive representations of arbitrary Scheme values, including lists, symbols, etc.

Initially I was reluctant to implement all of this functionality by hand in WASM text, but all alternatives ran into challenges:

1. Deferring this to the host is difficult because the host environment has no access to WASM GC references - they are completely opaque.
2. Implementing it in another language (maybe C?) and lowering to WASM is also challenging for a similar reason - the other language is unlikely to have a good representation of WASM GC objects.

So I bit the bullet and - with some AI help for the tedious parts - just wrote an implementation of write directly in WASM text; it wasn't really that bad. I import only two functions from the host:

(import "env" "write_char" (func $write_char (param i32)))
(import "env" "write_i32" (func $write_i32 (param i32)))

Though emitting integers directly from WASM isn't hard, I figured this project already has enough code and some host help here would be welcome. For all the rest, only the lowest level write_char is used. For example, here's how booleans are emitted in the canonical Scheme notation (#t and #f):

(func $emit_bool (param $b (ref $BOOL))
    (call $emit (i32.const 35)) ;; '#'
    (if (i32.eqz (struct.get $BOOL 0 (local.get $b)))
        (then (call $emit (i32.const 102))) ;; 'f'
        (else (call $emit (i32.const 116))) ;; 't'
    )
)

Conclusion

This was a really fun project, and I learned quite a bit about realistic code emission to WASM. Feel free to check out the source code of WasmCompiler - it's very well documented. While it's a bit over 1000 LOC in total [4], more than half of that is actually WASM text snippets that implement the builtin types and functions needed by a basic Scheme implementation.
